Vertical Vacuum Packing Machine

Download Sheet
Hygienic & Safe Design
Consistent Quality
International Standards
Secured Sealing
Advanced Vacuum Technology
Extended Shelf-Life

Types of packages

Vaccum
Gas Flushing

Products that can be packed

Sticky Powder
Pulses & Produce

Technical Specification

Production Capacity


Production Capacity

2 to 3 Cycles per Minute
Product to be Filled   Food Products, Agriculture Products, Pharmaceuticals, Electronics, Industrial Products, Etc.


Machine Specification


Vacuum Chamber Size

675 x 300 x 690 mm
Sealing Length

620 mm
Sealing Width

8 mm
No. of Sealing Bar

1
Sealing Type

Pneumatic

Packing Weight



10 Kg. to 25 Kg. (Depend on the Product)


Electrical Specification



Power Supply



3 H.P. (440 V AC)

Vacuum Pump



650 LPM

Control System



Timer Based Digital Electric Control System


Pneumatic Specification


Air Pressure   6 to 7 Bar


Machine Structure



Body Construction

   Stainless Steel 304

Vacuum Chamber

   Hygienic Stainless Steel 304

Machine Length



~ 2830 mm

Machine Width



~ 1234 mm

Machine Height



~ 955 mm


Required Accessories


Air Compressor   0.5 H.P.
