Web Sealer Machine
Consistent Quality
International Standards
Easy to Operate
High Production Output
Secured Shrinking
Types of packages
Wrapping
Shrink
Products that can be packed
 (1).png)
Cartons
.png)
Bottles
Technical Specification
Production Capacity |
|
|---|---|
| Packing Speed |
6 Pack / Minute |
| Maximum Packing Dimensions |
20” x 12” x 10" (L x W x H) |
Machine Specification |
|
|
Sealing Size |
26” (Hot Knife Technology) |
| Working Height |
16” |
| Conveyor |
M.S. Rod Type With Silicon Sleeve |
| Conveyor Load Capacity |
150 kg. |
| Conveyor Speed |
Variable (D.C. Drive) |
| Packing Material |
L.D. Shrink Film |
Electrical Specification |
|
| Conveyor Motor |
0.5 H.P., D.C. (1500 RPM) |
| No. of Heaters & Heater Watt |
30” (9 Pcs.) (1500 w) |
| Heater |
30” (U Type Finch) |
| Film Sealing Heater |
1 KW, 1 Heater (S.S. Tubuler Heater) |
| Temperature Range |
400 Degree |
| Power |
3-Phase |
| Power Consumption |
13 KW / 18 H.P. |
Pneumatic Specification |
|
| Required Air Pressure |
7 to 8 Bar. |
|
Pneumatic Componants |
Janatics |
|
|
|
Machine Structure |
|
|
M.O.C. |
M.S. Powder Coated |
| Machine Length | ~ 3735 mm |
| Machine Width | ~ 1220 mm |
| Machine Hight | ~ 1780 mm |
| Total Machine Weight | ~ 375 kg. |
Required Accessories |
|
| Air Compressor | 3 H.P. |
